Main Services
natural draft
Features
WOODEN MADE
- Fan Less
- Fill Less
- No Power
- No Maintenance
- No Breakdown
- No Downtime
- Lower Cost
- Lowest Operating Cost
- Aesthetically Appealing
- Longer Life
FRP MADE
- Structural in Pultruded FRP
- 100% Non-metallic, Corrosion Proof Towers
- All Cooling Tower Components as per IS, ASTM & CTI StandardS
- Apart From Our Standard Models, We Offer, Tailor / Custom Made Cooling Towers, to suit site conditions
- Low power cosumption
used material and other details
STRUCTURE: M.S. Hot dip galvanized angles, flats, tees etc. are bolted to form a strong structure. Structure of Pultruded FRP are optionally available for F.R.P cooling tower
Chemically treated pinewood columns, chords, diagonals etc. are bolted to form a rigid structure. Slots are accurately machined on vertical columns to hold louvers at proper angles for timber cooling tower.
LOUVRE: Moulded FRP louvers are fitted with vertical columns and each other by bolt, nut & washers for frp. Chemically treated pinewood louvers are slip fit into the grooves of vertical posts for timber.
BASIN: Basin is of Moulded FRP. The basin has internal brackets for fixing structure & external brackets to fix it with RCC/ Brick pads using foundation bolts for frp. The basin floor is of Marine plywood as per (IS-710) or treated timber. Bottom support & side planks of basin are of treated pinewood. Sealing compound is used for preventing any leakage. FRP basin is also optionally available for timber .
HOT WATER SPRAY PIPING |
SPRAY NOZZLES |
ACCESSORIES |
M.S. Hot dip galvanized main header & branch pipes are bolted on top of the tower structure. Piping in HDPE, P.P. PVC FRP coated, S.S. etc, is optionally available. |
